ABB ControlMaster CM10 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 97
230.010
(228.011)
WV 1 (2) Failed
Problem with input assigned to Loop 1 (2) wild variable.
Broken sensor leads, defective input source or input
signal out of permitted range.
Check wiring. Check input source.
Check if input signal is outside permitted limits
234.008
(232.009)
PFB 1 (2) Failed
Problem with input assigned to Loop 1 (2) position
feedback. Broken sensor leads, defective input source
or input signal out of permitted range.
Check wiring. Check input source.
Check if input signal is outside permitted limits
216.016
NV Error Proc Bd
Failure of non-volatile memory on processor / display
board or permanent corruption of its data .
Check all configuration parameters and correct any
errors. Acknowledge error.
If problem persists contact local service organization.
214.017
NV Error Main Bd
Failure of non-volatile memory on main board or
permanent corruption of its data.
Check calibration of AIN1, AIN2 and AO1. Recalibrate if
necessary. Acknowledge error.
If problem persists contact local service organization.
212.018
NV Error Opt Bd 1
Failure of non-volatile memory on option board 1 or
permanent corruption of its data.
Check calibration of AO2, AIN 3 and AIN4 (CM50 only).
Recalibrate If necessary. Acknowledge error.
If problem persists contact local service organization.
210.019
NV Error Opt Bd 2
Failure of non-volatile memory on option board 2 or
permanent corruption of its data.
Check calibration of AO2, AIN 3 and AIN4.
Recalibrate If necessary. Acknowledge error.
If problem persists contact local service organization.
Icon
Number /
Message
Possible Cause Suggested Action
Table 7.1 Diagnostic Messages (Continued)
