ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 10 Specification
IM/CM/I–EN Rev. P 91
Communications
Note. Only one communications option can be fitted per indicator.
IrDA service port (standard)
Ethernet (optional)
MODBUS* RTU (optional)
*MODBUS is a registered trademark of the MODBUS-IDA organization
Baud rate Up to 115 kBaud
Distance Up to 1 m (3 ft)
Functions Firmware upgrade
Configuration upload / download
Type 10BaseT
Connector RJ 45
Protocols TCP/IP
HTTP
MODBUS TCP (Slave)
Web server Built-in – enables remote monitoring using
standard web browsers
Email Can be configured to be sent on the occurrence
of a specified event
Up to 3 recipients
Up to 4 trigger sources with configurable tag
Baud rate Up to 115 kBaud
Isolation Galvanically isolated from the rest of the circuitry,
500 V DC for 1 minute
