Safety instructions
10
3ADW000462R0401 DCS880 Hardware manual e d
Installation and maintenance work
These warnings are intended for all who work on the drive, motor cable or motor.
Ignoring the instructions can cause physical injury or death and/or damage to the
equipment.
WARNING
-
Only qualified electricians are allowed to install and maintain the drive!
-
Never work on the drive, motor cable or motor when main power is applied.
-
Always ensure by measuring with a multimeter (impedance at least 1 MOhm)
that:
1. Voltage between drive input phases U1, V1 and W1 and the frame is
close to 0 V.
2. Voltage between terminals C+ and D- and the frame is close to 0 V.
-
Do not work on the control cables when power is applied to the drive or to the
external control circuits. Externally supplied control circuits may cause
dangerous voltages inside the drive even when the main power on the drive is
switched off.
-
Do not make any insulation resistance or voltage withstand tests on the drive or
drive modules.
-
Isolate the motor cables from the drive when testing the insulation resistance or
voltage withstand of the cables or the motor.
-
When reconnecting the motor cable, always check that the C+ and D- cables
are connected with the proper terminal.
Notes:
-
The motor cable terminals on the drive are at a dangerously high voltage when
the main power is on, regardless of whether the motor is running or not.
-
Depending on the external wiring, dangerous voltages (115 V, 220 V or 230 V)
may be present on the relay outputs of the drive system (e.g. XRO1 ... XRO3).
-
DCS880 with enclosure extension: Before working on the drive, isolate the
whole drive from the supply.
