Installation checklist
77
3ADW000462R0401 DCS880 Hardware manual e d
Installation checklist
Check the mechanical and electrical installation of the drive before start-up. Go through the checklist
below together with another person. Read the Safety instructions
on the first pages of this manual
before you work on the unit.
MECHANICAL INSTALLATION
The ambient operating conditions are allowed (see Environmental Conditions
, Current ratings)
The unit is mounted properly on a vertical non-flammable wall (see Mechanical installation)
The cooling air will flow freely (see Cabinet installation
, Mounting the converter module inside
an enclosure
The motor and the driven equipment are ready for start
All screen terminals are checked for tightness (see Connecting the signal and control cables
)
All cable connections are seated properly (see Connecting the signal and control cables
)
ELECTRICAL INSTALLATION (see Planning the electrical installation
, Electrical installation)
The converter modules are grounded properly
The mains voltage matches the converter module‘s nominal input voltage
The mains (input power) connections at U1, V1 and W1 (L1, L2 and L3) and their tightening
torques are OK
The appropriate mains fuses and disconnector are installed
The drive connections at C1, D1 and F+, F- and their tightening torques are OK
Motor cable routing (armature and exitation) is OK
Check that the screens are properly installed at the motor and the drive cabinet
The motor connections L+, L-, F+ and F- and their tightening torques are OK
The control connections are OK
If a pulse encoder is used, check the encoder cables and correct direction of rotation
PTC, klixon cables: Check that the connections are appropriate for the type of sensor used in
the motor
Check the Safe Torque Off (STO) circuit for proper function
Check the prevention of unexpected start-up (on inhibit, coast stop) circuit for proper function
Proper function of E-stop circuit and relay
Cooling fan power wiring connected
The external control connections inside the drive are OK
There are no tools, foreign objects or drill cuttings inside the drive
Converter, motor connection box and other covers are in place

ABB DCS880 series Specifications

General

Cooling Method	Air-cooled, liquid-cooled
Control Type	Direct Torque Control (DTC)
Communication Protocols	Ethernet, Modbus RTU, Modbus TCP, PROFIBUS DP, PROFINET, EtherCAT
Protection Class	IP00, IP21, IP54
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Ambient Temperature	-20 to +55 °C (derating may apply)
Input Voltage	3-phase, 380-830 V AC
