Type code
The type code contains information on the specification and configuration of the drive. The first digits from left show the basic configuration
(e.g. DCS880-S01-2000). The optional selections are given thereafter on the name plate by plus code. The main selections are described
below. Not all selections are available for all types.
The technical data and specifications are valid as of going to press. ABB reserves the right to make subsequent alterations.
The drive's basic type code: DCS880-aab-cccc-ddef + plus code
Product family DCS880
Product type: aa = S0
= R0
= E0
= A0
Standard converter module
Rebuild kit
Panel solution
Enclosed converter
Bridge type: b= 1
= 2
Single bridge (2-Q)
2 anti-parallel bridges (4-Q)
Module type: cccc = Rated DC current (IP00)
Rated AC voltage: dd = 04
= 05
= 06
= 07
= 08
= 10
= 12
100 V
AC
... 415 V
AC
100 V
AC
... 500 V
AC
(IEC), 525 V
AC
(UL)
270 V
AC
... 600 V
AC
315 V
AC
... 690 V
AC
360 V
AC
... 800 V
AC
450 V
AC
... 990 V
AC
540 V
AC
... 1190 V
AC
Power connection: e= X
= L
= R
Standard H1 ... H7
Left side H8
Right side H8
Revision code: f= 01
st
generation
Field exciter configuration: +0S163
+S164
H1 ... H4 without OnBoard field exciter
H5 and H6 with internal field exciter, supply external
(H5 and H6: 25 A, Rebuild kit: 16 A / 25 A)
Fan voltage:
Standard
Size H4
Fan voltage: 230 V / 1-ph
Application programming: +S551 Memory unit including drive application programming license
SDCS-DSL-H10: +S521 1 DCSLink channel, 0 channels optical power link SDCS-DSL-H10 (H1 ... H4)
Current measurement: +S175 SDCS-CMA-2 (H6 ... H8)
Voltage measurement: +S185 SDCS-PIN-H51 configured for 20 V
AC
... 100 V
AC
(H6 ... H8)
Control panel: +0J404
+J428
+J429
Without control panel
daisy-chain option DPI-H01 kit
Bluetooth control panel ACS-AP-W
