Technical data
79
3ADW000462R0401 DCS880 Hardware manual e d
Technical data
Chapter overview
The technical data contain the technical specifications of the converter, e.g. the ratings, sizes and technical
requirements, provisions for fulfilling the requirements for CE and other markings and warranty policy.
Environmental Conditions
Regulatory compliance
System connections Environmental limit values
Voltage, 3-phase: 100 ... 1000 V acc. to IEC 60038 Permissible cooling air temp.
100 ... 690 V acc. to UL508c - at converter module air inlet: 0 ... +55°C
Voltage deviation: IEC: -10% +15% continuous; with rated DC current: 0 ... +40°C
±20% short-time (0.5 to 30 cycles) with different DC current: +30 ... +55°C
UL: ±10 % continuous; - Options: 0 ... +40°C
±15 % short-time (0.5 to 30 cycles)Relative humidity (at 5...+40°C): 5 ... 95 %, no condensation
Rated frequency: 50 Hz or 60 Hz Relative humidity (at 0...+5°C): 5 ... 50 %, no condensation
Static frequency deviation: 50 Hz ± 2 %; 60 Hz ± 2 % Change of the ambient temp.: < 0.5°C / minute
Dynamic: frequency r
ange: 50 Hz ± 5 Hz; 60 Hz ± 5 Hz Storage temperature: -40 ... +55°C
df/dt: 17 % / s Transport temperature: -40 ... +70°C
Pollution degree (IEC 60664-1,
Please note: Special consideration must be taken for voltage IEC 60439-1): 2
deviation in regenerative mode.
Site elevation
Degree of protection < 1000 m above M.S.L.: 100 %, without current reduction
Converter module and options IEC: IP 00; acc. to IEC/EN 60529 > 1000 m above M.S.L.: with current reduction
(line chokes, fuses, field UL: open type acc. to UL 508c
exciters, etc.):
Overvoltage category
(all inp
uts):
Protective class:
III acc. to IEC 60664-1
I acc. to IEC 61800-5-1
Permissible supply systems: IT, TN, TT (neutral earthed)
IT (corner earthed)
TT (corner earthed)
Paint finish
Converter module: Body RAL 7012
Cover RAL 9017 & RAL 9002
Sound pressure level and vibration North American Standards
In North America the system components fulfil the requirements of
the table below.
Size Sound pressure level L
P
(1 m distance) Vibration
as module enclosed conv. as module
H1 55 dBA 68 dBA
3 mm, 2 - 9 Hz
1 g, 9 ... 200 Hz
H2 55 dBA 72 dBA
H3 60 dBA 78 dBA
H4 66 ... 70 dBA,
depending on fan
77 dBA
H5 75 dBA 77 dBA
0,3 mm, 2 - 9 Hz
0,1 g, 9 ... 200 Hz
H6 70 dBA 78 dBA
H7 69 dBA 67 dBA
H8 82 dBA 80 dBA
Rated supply
voltage
Standards
Converter module Enclosed converter
to 990 V UL 61800-5-1
Power Conversion Equipment
CSA C 22.2 No. 274-13
Industrial Control Equipment,
Industrial Products
Available for converter mod-
ules including field exciter
units. Types with UL mark:
• see UL Listing www.ul.com /
certificate no. E196914
• or on request
UL/CSA types: on
request
