Planning the electrical installation
61
3ADW000462R0401 DCS880 Hardware manual e d
Cross-sectional areas - Tightening torques
Recommended cross-sectional area to DINVDE 0276-1000 and DINVDE 0100-540 (PE) trefoil arrangement,
up to 50°C ambient temperature. The necessary wire torque at 60°C wire temperature is the same as
recommended in the following table.
Armature:
 Reduced ambient temperature 40°C.
You will find instructions on how to calculate the PE conductor’s cross-sectional area in VDE 0100 or
in equivalent national standards. We would remind you that power converters may have a current-
limiting effect.
Excitation:
Converter type C1, D1 U1, V1, W1 PE
[Nm]
I
DC
[A-]
1
[mm²]
(2.)
[mm²]
Iv
[A~]
[mm²] [mm²]
DCS880-S0B-0025-0d 25 1 x 6 - 21 1 x 4 1 x 10 1 x M6 6
DCS880-S0B-0050-0d 50 1 x 10 - 41 1 x 6 1 x 10 1 x M6 6
DCS880-S0B-0075-0d 75 1 x 25 - 61 1 x 25 1 x 16 1 x M6 6
DCS880-S0B-0100-0d 100 1 x 25 - 82 1 x 25 1 x 16 1 x M6 6
DCS880-S0B-0150-0d 150 1 x 35 - 114 1 x 35 1 x 16 1 x M10 25
DCS880-S0B-0200-0d 200 2 x 35 1 x 95 163 2 x 25 1 x 25 1 x M10 25
DCS880-S0B-0250-0d 250 2 x 35 1 x 95 204 2 x 25 1 x 25 1 x M10 25
DCS880-S0B-0300-0d 300 2 x 70 1 x 95 220 2 x 50 1 x 50 1 x M10 25
DCS880-S0B-0320-0d 320 2 x 70 1 x 95 220 2 x 50 1 x 50 1 x M10 25
DCS880-S0B-0350-0d 350 2 x 70 - 286 2 x 50 1 x 50 1 x M10 25
DCS880-S0B-0450-0d 450 2 x 95 - 367 2 x 95 1 x 95 1 x M10 25
DCS880-S0B-0520-0d 520 2 x 95 - 424 2 x 95 1 x 95 1 x M10 25
DCS880-S0B-0650-0d 650 2 x 120 - 555 2 x 120 1 x 120 1 x M12 50
DCS880-S0B-0680-0d 680 2 x 120 - 555 2 x 120 1 x 120 1 x M12 50
DCS880-S0B-0820-0d 820 2 x 150 - 669 2 x 120 1 x 120 1 x M12 50
DCS880-S0B-0900-06/07 900 4 x 95 3 x 150 734 4 x 70 1 x 150 2 x M12 50
DCS880-S0B-1000-0d 1000 2 x 185 - 816 2 x 150 1 x 150 1 x M12 50
DCS880-S0B-1190-0d 1190 4 x 120 - 971 4 x 95 2 x 95 2 x M12 50
DCS880-S0B-1200-0d 1200 4 x 120 - 979 4 x 95 2 x 95 2 x M12 50
DCS880-S0B-1500-0d 1500 4 x 185 - 1224 4 x 150 2 x 150 2 x M12 50
DCS880-S0B-2000-0d 2000 8 x 120 6 x 185 1632 4 x 240 2 x 240 2 x M12 50
DCS880-S0B-1900-0d 1900 8 x 120 6 x 185 1550 4 x 240 2 x 240 4 x M12 50
DCS880-S0B-2050-dd 2050 8 x 120 6 x 185 1673 6 x 120 3 x 120 4 x M12 50
DCS880-S0B-2500-0d 2500 7 x 185 - 2040 8 x 120 4 x 120 4 x M12 50
DCS880-S0B-2600-dd 2600 7 x 185 - 2122 8 x 120 4 x 120 4 x M12 50
DCS880-S0B-3000-0d 3000 8 x 185 - 2448 7 x 185 4 x 185 4 x M12 50
DCS880-S0B-3300-dd 3300 8 x 185 - 2693 7 x 185 4 x 185 4 x M12 50
DCS880-S0B-4000-dd 4000 7 x 300 - 3264 8 x 240 4 x 240 4 x M12 50
DCS880-S0B-4800-0d
 4800 8 x 300 - 3876 6 x 300 3 x 300 4 x M12 50
DCS880-S0B-5200-0d
 5200 8 x 300 - 4202 6 x 300 3 x 300 4 x M12 50
Size H1 H1 H2 H3, H5, H6 H4 DCF803-0035
DC output current 6 A 12 A 18 A 25 A 30 A 35 A
max. cross sectional area 6 mm²/ AWG 10 6 mm²/ AWG 10 6 mm²/ AWG 10 6 mm²/ AWG 10 6 mm²/ AWG 10 6 mm²/ AWG 10
min. cross sectional area 1 mm²/ AWG 16 2.5 mm²/ AWG 13 4 mm²/ AWG 11 6 mm²/ AWG 10 6 mm²/ AWG 10 6 mm²/ AWG 10
Tightening torque 1.5 ... 1.7 Nm

ABB DCS880 series Specifications

General

Cooling Method	Air-cooled, liquid-cooled
Control Type	Direct Torque Control (DTC)
Communication Protocols	Ethernet, Modbus RTU, Modbus TCP, PROFIBUS DP, PROFINET, EtherCAT
Protection Class	IP00, IP21, IP54
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Ambient Temperature	-20 to +55 °C (derating may apply)
Input Voltage	3-phase, 380-830 V AC
