Mechanical installation
25
3ADW000462R0401 DCS880 Hardware manual e d
Unpacking and examining the delivery (H6)
This illustration shows the layout of the transport package. Examine that all items are present.
Item Description
1 Drive with factory installed options.
2 Cardboard box.
3 Shock damper.
4 Lower and upper cardboard box cover.
5 Shock dampers.
6 Package containing documentation, plugs, mounting material, etc.
BG_DCS_001_verpackung_a.ai
1
2
3
4
4
5
5
6
