The DCS880
16
3ADW000462R0401 DCS880 Hardware manual e d
Plus codes
Option Option code Description
ACS-AP-I standard built-in
no ACS-AP-I 0J404 No Control Panel
ACS-AP-W +J429 Bluetooth panel
DPI-H01 +J428 daisy-chain option
FDNA-01 +K451 Fieldbus DeviceNet
FPBA-01 +K454 Fieldbus PROFIBUS
FCAN-01 +K457 Fieldbus CANOpen
FSCA-01 +K458 Fieldbus Modbus
FCNA-01 +K462 Fieldbus ControlNet
FECA-01 +K469 Fieldbus EtherCat
FEPL-02 +K470 Fieldbus Ethernet POWERLINK
FENA-11 +K473 Ethernet/IP, Modbus/TCP, Profinet
FENA-21 +K475 Ethernet/IP, Modbus/TCP, Profinet
FIO-11 +L500 Analog I/O Extension (3 AI, 1 AO, 2 DIO)
FIO-01 +L501 Digital I/O Extension (4 DIO, 2 RO)
FAIO-01 +L525 Analog I/O Extension (2 AI, 2 AO)
FDIO-01 +L526 Digital I/O Extension (3 DI, 2 RO)
FPTC-01 +L536 Thermistor protection module
FEN-01 +L517 TTL Encoder interface
FEN-21 +L516 Resolver Interface
FEN-31 +L502 HTL Encoder Interface
FDCO-01 +L503 DDCS communication 10/10 MBd
FDCO-02 +L508 DDCS communication 5/10 MBd
Application programming +S551 Memory unit including drive application programming license
no OnBoard field exciter 0S163 Excludes OnBoard field exciter (H1 ... H4)
SDCS-DSL-H10 +S521 1 DCSLink channel, 0 channels optical power link
FSO-21 +Q972 Functional Safety Option
FSE-31 +L521 Functional Safety Encoder
