ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
196 2CDC508198D0211 Rev. A | AC/S 1.x.1
Output sockets
Object name Data type
Actual room temperature
DPT 9.001
Outputs the actual room temperature
Signal value: -273...670760 °C
Room setpoint temperature
DPT 9.001
Outputs the current room setpoint temperature.
Signal value:
-273...670760 °C
Controller On/Off
DPT 1.001
The module has this output socket if any option except None is selected for the Controller On/Off parameter.
Outputs whether the room thermostat is switched on or off.
Signal value: 0 = Off
1 = On
Heating/cooling operating type DPT 1.100
The module has this output socket if any option except None is selected for the Heating/cooling operating type parameter.
Outputs the current heating/cooling operating type.
Signal value: 0 = Cooling
1 = Heating
Operating mode DPT 20.102
The module has this output socket if any option except None is selected for the Operating mode parameter.
Outputs the current HVAC operating mode.
Signal value:
0 = Auto
1 = Comfort
2 = Standby
3 = Economy
4 = Building Protection
