Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 199
Object name
Data type
Fan coil unit, additional-stage heating DPT 1.001
DPT 5.001
The data point type for the output socket is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the On/Off option is selected for the
Fan coil unit,
additional-stage heating parameter:
DPT 1.001
Signal value: 0 = Off, 1 = On
• If any option except None is selected for the Fan coil unit
parameter and the 0…100% option is selected for the Fan coil
unit, Fan coil unit, additional-stage heating parameter:
DPT 5.001
Signal value: 0…100%
Outputs the status of the additional-stage heating
Fan coil unit, fresh air damper
DPT 1.019
DPT 5.001
The data point type for the output socket is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the Open/Closed option is selected for the
Fan
coil unit, fresh air damper parameter:
DPT 1.019
Signal value: 0 = Closed, 1 = Open
• If any option except None is selected for the Fan coil unit parameter and the 0…100% option is selected for the
Fan coil
unit, fresh air damper parameter:
DPT 5.001
Signal value: 0…100%
Outputs the position of the fresh air damper.
Fan coil unit, fan speed
DPT 5.001
DPT 5.010
The data point type for the output socket is dependent on the settings in the module.
• If any option except None is selected for the Fan coil unit parameter and the Display or Display+set (slave) DPT 5.001
option is selected for the Fan coil unit, fan speed parameter:
DPT 5.001
Signal value: 0…100%
• If any option except None is selected for the Fan coil unit
parameter and the Display+set (slave) DPT 5.010 option is
selected for the Fan coil unit, fan speed parameter:
DPT 5.010
Signal value: 0…5
Outputs the current fan speed.
