Parameters
224 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Object type
Unit
COV send
condition
Room: Floor heating, valve
Binary value
Analog value
-
% (98)
-
1.0
Outputs the position of the floor heating valve.
The object type for the object is dependent on the settings in the module:
• If the On/Off option is selected for the Floor heating
parameter:
Object type binary value
Unit –
Send condition –
Signal value 0 = Off, 1 = On
• If the 0…100 % option is selected for the Floor heating
parameter:
Object type analog value
Unit % (98)
Send condition 1.0
Signal value 0…100 %
Room: Floor temperature sensor Analog value °C (62) 1.0
The module has this BACnet output object if the
On/Off
option or the
0…100 %
option is selected for the
Floor heating
parameter and the Yes option is selected for the Floor temperature sensor parameter.
Outputs the floor temperature.
Signal value:
-273...670760 °C
Room: Cooling ceiling, valve Binary value
Analog value
-
% (98)
-
1.0
Outputs the position of the cooling ceiling valve.
The object type for the object is dependent on the settings in the module:
• If the On/Off option is selected for the Cooling ceiling
parameter:
Object type binary value
Unit –
Send condition –
Signal value 0 = Off, 1 = On
• If the 0…100 % option is selected for the Cooling ceiling
parameter:
Object type analog value
Unit % (98)
Send condition 1.0
Signal value 0…100 %
