– Be at a distance that does not exceed the maximum or recommended field wiring lengths for
connections to peripherals or external equipment. Field wiring requirements depend on the type of
connection. See section 3.1.5
.
3.1.4 Mounting requirements
Mounting surfaces or walls require enough strength to support the hanging weight of the enclosure, and
associated equipment to meet the requirements of IEC715.
3.1.5 Install antenna (for wireless functionality)
IMPORTANT NOTE:
The Wi-Fi Kit 2106123 is required for antenna installation. See Additional
information
.
3.2 Wiring requirements
Field wiring must meet the following requirements:
– All wiring connections and the screw terminals for power support 14 – 24 AWG and communications
support 16 - 24 AWG. Select the wire gauge according to the voltage and current requirements of the
circuitry. The gauge differs for each application.
– Follow local electrical codes to select the appropriate wire gauge and type based on the load current,
voltage, signal type, and indoor or outdoor environment.
NOTICE
– Equipment damage.
Field installation cable and conductors must be rated greater than
70
°C (158 °F) when installed in an ambient temperature of 60 °C (140 °F).
3.3 Unpack and inspect
The XIO and additional parts ship in a specially designed shipping carton with a Quick Start Guide, Safety
and Compliance notice, and packing list.
IMPORTANT NOTE
: If there is any damage to the shipping carton, keep it and the packing
materials until the conten
ts are inspected and found to be free of damage.
To unpack the XIO and inspect for damaged, missing or incorrect parts:
– Inspect the shipping carton for damage.
– Carefully remove items from the carton.
– Keep all shipping materials to return parts.
– Compare the packing list with the materials received. Check for any missing or incorrect parts.
– Inspect each item for damage: XIO exterior and optional equipment, if purchased.
If there are missing, incorrect, damaged parts or noticeable defects, call the ABB main office number
listed on the last page of this manual.
3.4 Basic hardware installation
This is an overview of a typical hardware installation. For different installations, call the ABB main office
number listed on the last page of the manual.
