102 ZX2 GAS-INSULATED MEDIUM VOLTAGE SWITCHGEAR
ABB part number
Accessories for visible grounding by grounding set
Grounding set for inner cone, size 2,
29.5 kA
GCE0920226P0107
Grounding set for inner cone, size 3,
29.5 kA
GCE0920226P0108
Rod for grounding set, hinged GCE0920226P0109
Wall mounting for grounding set 1VB0000074P0100
Accessories for capacitive
Display unit (fig. 6.1.1) GCE0931333P0101
Interface tester GCE0900052P0102
Short-circuiting plug GCE0909005P0100
Other accessories
Lifting section for fork lift truck
(fig. 2.4.1.1, 2.4.1.2)
GCE9015358R0102
Double bit key for barrel lock in panel
door
GCE0990108P0100
Wall mounting for accessories 1VB8000533R0101
Adapter for DILO filling
truck for filling valve (further
adapters on request)
Adapter for thread M 24 x 1.5 1VB8004776P0101
Adapter for thread M 20 x 1.5 (DN8) 1VB8007470P0101
Hose connector GCE0905093P0100
10.3. Accessories
ABB part number
Accessories for manual charging of the stored
energy spring of the circuit-breaker
Charging lever for VD4 X operating
mechanism (fig. 5.5.1.2)
GCE9477394R0101
Accessories for emergency manual operation of the
three-position disconnect and the disconnect
Crank for emergency manual
operation, length: 795 mm (31.3 in)
(standard, fig. 5.5.2.4)
GCE7006002R0103
Crank for emergency manual
operation, length: 1209 mm (47.6 in)
GCE7006002R0102
Accessories for operation of the isolating
device in metering panels
Key for isolating device, hex. 17/350 1VB0000038P0100
Accessories for the voltage transformer truck
Crank (fig. 3.3.7.1.7) GCE8008184P0101
Testing accessories
Voltage testing plug up to 36 kV for
inner cone, size 2
GCE0920226P0101
Voltage testing plug up to 36 kV for
inner cone, size 3
GCE0920226P0102
Voltage testing cable up to 36 kV for
inner cone, size 2
GCE0920226P0105
Voltage testing cable up to 36 kV for
inner cone, size 3
GCE0920226P0106
Current testing plug for inner cone,
size 2, I
N
= 800 A, I
P
= 2500 A / 4 min.
GCE0920226P0103
Current testing plug for inner cone,
size 3, I
N
= 1250 A, I
P
= 3150 A / 4 min.
GCE0920226P0104
Blanking plugs
Blanking plug for inner cone, size 2 GCE8011949R0101
Blanking plug for inner cone, size 3 GCE0909097P0100
