6 ZX2 GAS-INSULATED MEDIUM VOLTAGE SWITCHGEAR
You have chosen a gas-insulated switchgear of
series ZX2. This switchgear from the ZX range is
notable for the following features:
• SF
6
gas-insulated with hermetically sealed pres-
sure systems
• Rated voltages up to 38 kV
• Up to 3000 A and 40 kA
• Single busbar and double busbar design
• Up to 5000 A in single busbar design
• Stainless steel enclosures, fabricated from laser
cut sheet steel
• Modular structure
• Switchgear with a leakage rate of less than
0.1 % per year
• Integral routine leakage testing of the panels
ex-works
• Indoor installation
• Panel widths 23.62 in, 31.50 in and 33.1 in
If you have technical questions, please contact our service staff
Power technology customer service Call number +1 843 413 4702
Switchgear IEC 62271-1 Common specifications for high-voltage switchgear and controlgear standards
Switchgear IEC 62271-200
High-voltage switchgear and controlgear
Part 200: A.C. metal-enclosed switchgear and controlgear for rated voltages above
1 kV and up to and including 52 kV
Circuit-breaker IEC 62271-100
High-voltage switchgear and controlgear
Part 100: High voltage alternating current circuit-breakers
Disconnect and grounding switch IEC 62271-102
High-voltage switchgear and controlgear
Part 102: Alternating current disconnects and grounding switches
prevention regulations of the country in which the switchgear is operated and the safety data sheets for the used auxiliary materials.
IEC 60364 Low-voltage electrical installations
IEC 61936 Power installations exceeding 1 kV a.c.
EN 50110 Operation of electrical installations
National technical accident prevention regulations e.g. for electrical systems and equipment and SF
6
installations
Safety data sheets for auxiliary materials
1. Standards, regulations,
notes, further documents
