40 ZX2 GAS-INSULATED MEDIUM VOLTAGE SWITCHGEAR
—
Fig. 3.3.5.3:
Installation of the
connecting conduc-
tors (simplified)
Voltage transformer socket
Top-mounted box
Fastening screw for the upper flat conductor
Assembly opening
Upper flat conductor (turned out of the
Countersunk screw M 8 x 25 DIN 7991-8.8
Dished washer 8 DIN 6796-FST
Hexagonal nut M 8 DIN 934-8
Flat conductor in the adapter box
Adapter box
