ABOV SEMICONDUCTOR MC81F4204 - PWM2 DR and PWM3 DR Data Registers

MC81F4204
110 April 24, 2012 Ver.1.41
PWM2DR
PWM 2 DATA REGISTER 00D0H
7 6 5 4 3 2 1 0
PWM2DR
One byte register Reset value: FFH
R/W R/W R/W R/W R/W R/W R/W R/W
A 8-bit data register for lower bits of 10-bit PWM 2 duty value.
PWM3DR
PWM 3 DATA REGISTER 00D1H
7 6 5 4 3 2 1 0
PWM3DR
One byte register Reset value: FFH
R/W R/W R/W R/W R/W R/W R/W R/W
A 8-bit data register for lower bits of 10-bit PWM 3 duty value.
