11.6 Interrupt Vector & Priority Table
Address Interrupt INT number Priority
0FFE0H Basic Interval Timer INT0 15 ( lowest priority)
0FFE2H Watchdog Timer INT1 14
0FFE4H - - 13
0FFE6H Timer 2 match/overflow INT3 12
0FFE8H Timer 1 match/overflow INT4 11
0FFEAH Timer 0 match/overflow INT5 10
0FFECH - - 9
0FFEEH - - 8
0FFF0H SIO INT8 7
0FFF2H - - 6
0FFF4H External Group INT10 5
0FFF6H External 6 INT11 4
0FFF8H External 5 INT12 3
0FFFAH External 3 INT13 2
0FFFCH External 1 INT14 1
0FFFEH RESET INT15 0 ( highest priority)
Note : External Interrupt Group = (EXT0, EXT2, EXT4, EXT7 – EXT11)
Table 11-1 Interrupt Vector & Priority
