7. ELECTRICAL CHARACTERISTICS
7.1 Absolute Maximum Ratings
Parameter Symbol Ratings
Unit
Note
Supply Voltage VDD -0.3 – +6.0
V
–
VI -0.3 – VDD+0.3
V
VO -0.3 – VDD+0.3
V
Voltage on any pin with respect
to Vss
IOH -10
mA Maximum current output sourced
by (IOH per I/O pin)
ΣIOH -80
mA
Maximum current (ΣIOH)
IOL 15
mA Maximum current sunk by (IOL
per I/O pin)
Normal Voltage Pin
ΣIOL 120
mA
Maximum current (ΣIOL)
Total Power Dissipation fXIN 600
mW
–
Storage Temperature TSTG -65 – +150
°C
–
Note :
Stresses above those listed under “Absolute Maximum Ratings” may cause permanent
damage to the device. This is a stress rating only and functional operation of the device at
any other conditions above those indicated in the operational sections of this specification is
not implied. Exposure to absolute maximum rating conditions for extended periods may affect
device reliability.
7.2 Recommended Operating Conditions
Parameter Symbol Conditions Min Typ
Max Units
fx = 1.0 – 4.2MHz 2.2
-
5.5
fx = 1.0 – 8.0MHz 2.7 - 5.5
Operating Voltage
V
DD
fx = 1.0 – 12.0MHz 4.0 - 5.5
V
Operating
Temperature
TOPR VDD = 2.2 – 5.5V -40 85 °C
