MC81F4204
138 April 24, 2012 Ver.1.41
25.2 Basic ISP S/W Information
The
Figure 25-1 is the USB_SIO_ISP software based on MS-Windows. This software supports only
SIO_ISP type devices.
Function Description
Load File Load the data from the selected file storage into the memory buffer.
Save File
Save the current data in your memory buffer to a disk storage by using the
Intel Motorola HEX format.
Blank Check
Verify whether or not a device is in an erased or un-programmed state.
Program This button enables you to place new data from the memory buffer
into the target device.
Program Write the current data into the MCU.
Read
Read the data in the target MCU into the buffer for examination. The
checksum will be displayed on the checksum box.
Verify
Assures that data in the device matches data in the memory buffer. If your
device is secured, a verification error is detected.
Figure 25-1 ISP Software
