7.5 DC Electrical Characteristics (Continued)
(T
A
= - 40
°
C to + 85
°
C, V
DD
= 2.2 – 5.5V, Vss=0V, fXIN=12MHz)
Parameter Symbol Conditions Min Typ Max Units
OSC feedback
resistor
RX
Xin=VDD, Xout=VSS
TA=25
°
C, VDD=5V
350 700 1500 MΩ
Active mode,
fx=12MHz, VDD=5V±10%
Crystal oscillator
– 8.0 15.0
IDD1
fx=8MHz, VDD=3V±10% – 3.0 6.0
mA
Sleep mode,
fx=12MHz, VDD=5V±10%
Crystal oscillator
– 2.0 4.0
ISLEEP1
fx=8MHz, VDD=3V±10% – 1.0 2.0
mA
Supply current
ISTOP
Stop mode
VDD=5.5V, TA=25
°
C
– 0.5 5.0 uA
POR level 1.82 2.1 V
7.6 Input/Output Capacitance
(T
A
= - 40
°
C to + 85
°
C, V
DD
= 0 V)
Parameter Symbol Conditions Min Typ Max Units
Input Capacitance CIN
Output Capacitance COUT
I/O Capacitance CIO
f=1MHz
Unmeasured pins
are connected Vss
– – 10 pF
