11.1 Registers
IENH
INTERRUPT ENABLE HIGH REGISTER 00EAH
7 6 5 4 3 2 1 0
IENH
T0MIE T0OVIE T1MIE T1OVIE T2MIE T2OVIE - -
Reset value: 00H
R/W R/W R/W R/W R/W R/W R/W R/W
0: Disable interrupt
T0MIE
Timer 0 Match Interrupt Enable Bit
1: Enable interrupt
0: Disable interrupt
T0OVIE
Timer 0 Overflow Interrupt Enable Bit
1: Enable interrupt
0: Disable interrupt
T1MIE
Timer 1 Match Interrupt Enable Bit
1: Enable interrupt
0: Disable interrupt
T1OVIE
Timer 1 Overflow Interrupt Enable Bit
1: Enable interrupt
0: Disable interrupt
T2MIE
Timer 2 Match Interrupt Enable Bit
1: Enable interrupt
0: Disable interrupt
T2OVIE
Timer 2 Overflow Interrupt Enable Bit
1: Enable interrupt
-
bit 1 – bit 0 Not used for MC81F4204
IENL
INTERRUPT ENABLE LOW REGISTER 00EBH
7 6 5 4 3 2 1 0
IENL
- SIOIE - - - WDTIE – BITIE
Reset value: 00H
R/W R/W R/W R/W R/W R/W – R/W
–
bit 7 Not used for MC81F4204
0: Disable interrupt
SIOIE
SIO Interrupt Enable Bit
1: Enable interrupt
–
bit5 – bit 3
Not used for MC81F4204
0: Disable interrupt
WDTIE
Watchdog Timer Interrupt Enable Bit
1: Enable interrupt
–
bit1 Not used for MC81F4204
0: Disable interrupt
BTIE
Basic Timer Interrupt Enable Bit
1: Enable interrupt
