BIT manipulation
NO. MNEMONIC
OP
CODE
BYTE
NO
CYCLE
NO
OPERATION
FLAG
NVGBHIZC
1 AND1 M.bit 8B 3 4
Bit AND C-flag : C ← ( C ) ∧ ( M.bit )
-------C
2 AND1B M.bit 8B 3 4
Bit AND C-flag and NOT :
C ← ( C ) ∧ ~( M.bit )
-------C
3 BIT dp 0C 2 4
4 BIT !abs 1C 3 5
Bit test A with memory :
Z ← ( A ) ∧ ( M ), N ← ( M7 ), V ← ( M6 )
MM----Z-
5 CLR1 dp.bit y1 2 4
Clear bit : ( M.bit ) ← “0”
--------
6 CLRA1 A.bit 2B 2 2
Clear A bit : ( A.bit ) ← “0”
--------
7 CLRC 20 1 2
Clear C-flag : C ← “0”
-------0
8 CLRG 40 1 2
Clear G-flag : G ← “0”
--0-----
9 CLRV 80 1 2
Clear V-flag : V ← “0”
-0--0---
10 EOR1 M.bit AB 3 5
Bit exclusive-OR C-flag : C ← ( C ) ⊕ ( M.bit )
-------C
11 EOR1B M.bit AB 3 5
Bit exclusive-OR C-flag and NOT :
C ← ( C ) ⊕ ~( M.bit )
-------C
12 LDC M.bit CB 3 4
Load C-flag : C ← ( M.bit )
-------C
13 LDCB M.bit CB 3 4
Load C-flag with NOT : C ← ~( M.bit )
-------C
14 NOT1 M.bit 4B 3 5
Bit complement : ( M.bit ) ← ~( M.bit )
--------
15 OR1 M.bit 6B 3 5
Bit OR C-flag : C ← C ∨ ( M.bit )
-------C
16 OR1B M.bit 6B 3 5
Bit OR C-flag and NOT : C ← C ∨ ~ ( M.bit )
-------C
17 SET1 dp.bit x1 2 4
Set bit : ( M.bit ) ← “1”
--------
18 SETA1 A.bit 0B 2 2
Set A bit : ( A.bit ) ← “1”
--------
19 SETC A0 1 2
Set C-flag : C ← “1”
-------1
20 SETG C0 1 2
Set G-flag : G ← “1”
--1-----
21 STC M.bit EB 3 6
Store C-flag : ( M.bit ) ← C
--------
22 TCLR1 !abs 5C 3 6
Test and clear bits with A :
A – ( M ), ( M ) ← ( M ) ∧ ~( A )
N-----Z-
23 TSET1 !abs 3C 3 6
Test and set bits with A :
A – ( M ), ( M ) ← ( M ) ∨ ( A )
N-----Z-
