MC81F4204

April 24, 2012 Ver.1.41 55

Address

Mnemonic

Hex

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

T0SCR 00B0H

–

T0MS T0CC T0CS

T0DR 00B1H Timer 0 Data Register

T0CR 00B2H Timer 0 Counter Register

T1SCR 00B3H

–

T1MS T1CC T1SCR

T1DR 00B4H Timer 1 Data Register

T1CR 00B5H Timer 1 Counter Register

T2SCR 00B6H

– –

T2MS T2CC T2SCR

T2DR 00B7H Timer 2 Data Register

T2CR 00B8H Timer 2 Counter Register

ADMR 00BDH SSBIT EOC ADCLK ADCH

ADDRH 00BEH A/D Converter Data Register High Byte

ADDRL 00BFH A/D Converter Data Register Low Byte

R0 00C0H R0 Port Data Register

R1 00C1H R1 Port Data Register

R3 00C3H R3 Port Data Register

R0CONH 00C6H R07 R06

–

R05

R0CONM 00C7H R05 R04 R03

R0CONL 00C8H

– –

R02 R01 R00

PUR0 00C9H PUR07 PUR06 PUR05 PUR04 PUR03 PUR02 PUR01 PUR00

EINT0H 00CAH EXT5IE EXT4IE EXT3IE EXT2IE

EINT0L 00CBH EXT1IE EXT0IE EXT11IE EXT10IE

ERQ0 00CCH EXT5IR EXT4IR EXT3IR EXT2IR EXT1IR EXT0IR EXT11IR EXT10IR

EINTF 00CDH EXT0IF EXT2IF EXT4IF EXT7IF EXT8IF EXT9IF EXT10IF EXT11IF

PWMSCR 00CEH

–

POL3 POL2 PWMS

– – – –

PWMPDR 00CFH

– –

P3DH P3DL P2DH P2DL PPH PPL

PWM2DR 00D0H PWM 2 Data Register

PWM3DR 00D1H PWM 3 Data Register

R1CONH 00D3H

– – – – – –

R14

R1CONM 00D4H R13 R12

– –

R1CONL 00D5H

– – –

R11 R10

PUR1 00D6H

– – –

PUR14 PUR13 PUR12 PUR11 PUR10

EINT1 00D7H EXT9IE EXT8IE EXT7IE EXT6IE

ERQ1 00D8H

– – – –

EXT9IR EXT8IR EXT7IR EXT6IR

Table 9-3 Control Register 3/4
