snoitarugifnoC dna snoitacificepS erawdraH21-1
Rear View
0
Figure 1-4. Base View
Table 1-4. Base View
# Icon Item Description
1 IR Blaster Port Connects to a set-top box
2 TV Tuner Connector Connects to a TV cable
3 Audio Jack Connects to external audio source
4 Ethernet (RJ-45) Port Connects to an Ethernet 10/100/1000-based
network
5 USB 2.0 Ports Connect to USB 2.0 devices (e.g., USB mouse,
USB camera, USB keyboard)
6 DC-in Jack Connects to an AC adapter
