This chart also includes the causes of the error messages and what to do to solve them:
$/%

%!!"H%

%!&0-$

%!%"8#%

E101
memory fail
EEPROM fault
NO
E102
memory fail
I
2
C bus EEPROM fault
NO
E103
memory fail
EEPROM DMA readings fault
NO
E104
memory fail
EEPROM DMA writings fault
NO
E105 no response from generator
Lost communication between inverter
and generator
NO
E106
wrong response from generator
NAK response from inverter
YES
E107
emission start fail
YES
E108
emission too long
YES
E109
button released
beforehand
YES
E110 wrong use of button
pressione pulsante di esposizione in
situazione di “pronto” disattivo
YES
E111
keyboard pressed at boot
Keyboard pressed during boot time
NO
E112
button
pushed at boot
Exposure button pressed beforehand
NO
E113
wrong use of keyboard
Keys pressed during an exposure
YES
E114 button release timeout
Exposure button released beforehand
after an exposure
YES
E115 wrong parameters in generator
Exposure parameters (kV, mA,
exposure time, mode) does not match
with the ones set in the control box
YES
E116 generator reset during emission
inverter has been resetted during an
exposure
YES
E117
calibration start fail
Calibration
YES
E118
calibration too long
Calibration tme too long
YES
E119 button pushed during cooling
Exposure button pressed beforehand
pushed during a functionality exposure
YES
E120
cooling time disabled
Functionality pause disabled
YES
E121 button pushed during standby
Exposure button pressed beforehand
during standby
YES
E122
memory fail
Parameters out of range
NO
E123
power relay fail
power relay failure (relay OFF)
NO
E124
power relay fail
power relay failure (relay ON)
NO
E125
power board fail
power board failure
NO
E126
power board fail
power board failure
NO
E127
power board fail
power board failure
NO
E128
power board fail
power board failure
NO
E201
generator memory
Inverter EEPROM error
NO
E202
generator memory
Inverter I
2
C EEPROM error
NO
E203
generator memory
Inverter EEPROM DMA readings fault
NO
E204
generator memory
Inverter EEPROM DMA writings fault
NO
