E205
generator not calibrated
Calibration not yet done
YES
E206
tube voltage too low
Anodic
voltage too low
YES
E207
tube voltage too high
Anodic voltage too high
YES
E208
electrical discharge on hv
YES
E209
tube current too low
Anodic current too low
YES
E210
tube current too
high
Anodic current too high
YES
E211
filament voltage too low
Filament voltage too low
YES
E212
filament voltage too high
Filament voltage too high
YES
E213
tube unit not connected
High
voltage unit not connected
NO
E214 button released beforehand
Enable signal released beforehand
during an exposure
YES
E215
generator internal power supply
12V internal voltage too low
NO
E216
generator internal power supply
12V internal voltage too high
NO
E217 generator mode
Wrong exposure enabling signal
activation
YES
E218
safe circuit fail
Security interlock fault
NO
E219
tube current too low
Mean anodic current too low
YES
E220
tube current too high
Mean anodic current too high
YES
E221
no tube voltage feedback
Missing HV feedback
NO
E222
ACE acquisition fail
X

rays not detected by Sopix
YES
