Identifying Parts of the NAS System · Installation

Rear View

HDD Status LEDs

Green LED indicates power is on and the hard disk drive status is good for this slot.Blinking Orange and

Green LED indicates the hard disk drive is in rebuilding state.

Power Supply

eSATA Expansion Port

AC Power Input Socket

COM 1

FAN

LAN 0 Gigabit Port

LAN 1 Gigabit Port

4x USB 2.0 Port

Audio Line IN

Audio Line Out

Audio Mic. IN
