Open ADR Virtual End Node (VEN)
The nLight ECLYPSE is available with a software module that embeds Open Automated Demand Response (OpenADR)
2.0a Virtual End Node (VEN) capability directly into the controller, eliminating the requirement for a separate system com-
ponent that acts as a VEN. Ordering the nECY with the “ADR” option enables this software module and provides the nECY
with the ability to control nLight Wired and Air devices to reduced light levels during Demand Response (DR) events.
Figure81: Open ADR configuration in the ECLYPSE web interface
Item Description
Open ADR
Toggle On or Off the Open ADR functionality
VTN Url
Enter the URL of the Virtual Top Node (VTN).
You must also choose between http:// or https:// connection. If using https://, you will be required to upload a public and private
certificate, as well as have the option of verifying the Hostname.
VTN ID Enter the VTN ID code.
VEN NAME Enter the Virtual End Node (VEN) name.
VEN ID Enter VEN ID code.
Click to refresh the information in the list.
Active Event The Active Event button displays any active Open ADR events associated with the controller.
Opt Out This will signal the VEN to not participate in an event.
Start Test Event
Click to start a test event. Test events demonstrate DR commissioning to the owner and/or commissioning agent. Each test
event lasts one minute and can be assigned an Automated Demand Response severity level of
Normal
,
Low
,
Medium
and
Max
.
Click the button again to stop the test event before the one minute is up.
Apply Click
Apply
to apply and save the changes.
ECLYPSE Web Interface
80
nLight ECLYPSE
