6243/44 DC Voltage Current Source/Monitor Operation Manual
3.3.12 RANGE key (Source Range)
3-18
3.3.12 RANGE key (Source Range)
Pressing the RANGE key changes the source range and limiter range.
The (Down) key: Moves to the lower range.
The (Up) key: Moves to the higher range.
3.3.13 RECALL key (Measurement Data Recall)
Pressing the RECALL key displays the screen for recalling the measurement data stored in the measure-
ment data buffer.
To recall the measurement data, specify the memory address with the , keys and the Data knob.
To restore the normal measurement screen, press the RECALL key again.
3.3.14 RUN HOLD key (Measurement Free Run/Hold)
Pressing the RUN HOLD key switches measurement in the DC source mode and Pulse source mode
between Free Run and Hold.
Free Run: Measurement and pulse source are performed in accordance with the cycle of the
set Period Time (Tp). At this time, * is shown to the left of the source mode indi-
cation in the lower right of the screen.
Hold: Measurement and pulse source are performed by the START TRIGGER key,
GPIB trigger command, or the signal input through the TRIGGER IN terminal
on the rear panel. At this time, the * shown to the left of the source mode indica-
tion in the lower right of the screen is OFF.
3.3.15 START TRIGGER key (Sweep Start, Measurement Trigger)
Pressing the START TRIGGER key starts sweep or measurement.
When Hold is selected in the DC source mode and Pulse source mode, measurement or pulse source is
performed.
In the DC Sweep source mode and Pulse Sweep source mode, the sweep is started.
3.3.16 STOP key (Sweep Stop)
Pressing the STOP key stops sweep.
When the sweep is stopped, the bias value is output.
