6243/44 DC Voltage Current Source/Monitor Operation Manual
4.5 Source Functions
4-21
4.5 Source Functions
The following explain operations and restrictions about source.
4.5.1 Changing the Source Mode and Source Function
When the Source Mode or Source Function is changed, the source value and limiter value change as shown
in Figure 4-13.
Figure 4-13 Changing the Source Mode and Source Function
(1) Function change examples
• Each press on the VS/IS key switches the setting as follows:
VS: +1.0000 V L: 0500.0 mA

IS: +0500.0 mA L: 1.0000 V
• Pressing the VS/IS key twice switches the setting as follows:
VS: +0.0000 V L: 0500.0 mA

IS: +0500.0 mA L: 0.0300 V

VS: +0.0300 V L: 0500.0 mA
• When the VS or IS value is set to 300 digits or less, the limiter value is set to the
minimum value of 300 digits.
DC V
DC I
PLS V
PLS I
SWP V
SWP
PSW V
PSW I
VS
IS
VS
IS
Vbi
Ibi
Vbi
Ibi
IS
VS
IS
VS
IS
VS
IS
VS
Source Limiter
Display
Internal data
Source
mode
function
IS
Ibi
VS
Vbi
Source/Limiter
Bias
VI
