4.5.3 Source Range
4-23
(2) Restrictions on each source value
Base value: The polarity specified at the time of setting is ignored and becomes the same as
that of the pulse value.
Start value: 0 generates an error for log sweep.
Stop value: 0 generates an error for log sweep.
Step value: The polarity specified at the time of setting is ignored and sweep proceeds from
Start  Stop.
In linear sweep: (Stop - Start) / Step + 1  5000 generates an error.
In log sweep: If the polarities of start and stop are not identical, an er-
ror is generated.
When |Start|  |Stop|, an error is generated.
If an error is generated, operation is not possible.
4.5.3 Source Range
(1) Source ranging
• The source values (pulse values) of the DC mode and pulse source mode are output in the dis-
played range.
• Base value, bias value, start value and stop value ranges are decided by the fixed/auto range as
shown in the following table with no relation to the set values or displayed values.
Range Operation Selected range
Fixed range
Data knob
Direct mode without unit
Specified range
Fixed range in the Sweep mode Maximum range to cover the source
values
Auto range
Direct mode with unit
Auto range in the Sweep mode
Maximum range to cover the source
digits
