6243/44 DC Voltage Current Source/Monitor Operation Manual
A.3.1 GPIB Remote Execution Time (Nominal Values)
A-7
• Time from trigger input (*TRG) to measurement and data output completion to GPIB
• Time from source command reception + trigger input (*TRG) to measurement and data output
completion to GPIB
DC, pulse source mode
(3) Data read time
(4) Time from sweep start to data read
Time for data output completion from memory to GPIB by RN1 command for 100-step sweep
Conditions: Source range: Fixed Range
Measurement range: Fixed. Trigger mode: Internal trigger.
Measurement digits: 5-1/2 digits. Integration time: 500 s.
Measure delay: 0.3 ms. Hold time: 3 ms. Source delay: 10 s. Pulse width: 1 ms.
Header: OFF. Block delimiter: EOI (DL2)
Source value condition Execution time
When the DC, Pulse or Sweep step value is generated: 18 ms
When the Sweep start value is generated: 23 ms
Source Command Execution time
Voltage
source
D<data> (Without unit, <data>: 1 character) 29 ms
D<data>unit (With unit, <data>: 1 character) 31 ms
Current
source
D<data> (Without unit, <data>: 1 character) 32 ms
D<data>unit (With unit, <data>: 1 character) 35 ms
Item No. of data Execution time
Source value reading time by query 1 16 ms
Measurement buffer memory reading time after
submitting the RN1 command
Condition: Number of measurement digits: 5 1/2,
header: OFF, Block delimiter: EOI(DL2)
110 ms
100 710 ms
Memory mode Period Execution time
Normal-ON 10 ms 1.7 s
Burst-ON 4 ms 1.3 s
