A.3.1 GPIB Remote Execution Time (Nominal Values)
A-6
(2) Measurement execution time
Conditions: Source range: Fixed Range
Measurement range: Fixed. Trigger mode: External trigger.
Measurement digits: 5-1/2 digits.
Integration time: 500 s. Measure delay: 0.3 ms. Source delay: 10 s.
Period: 2 ms. Pulse width: 1 ms
Header: OFF. Block delimiter: EOI (DL2)
Current
source /
Current
limiter*
Source value
Limiter value
Pulse value
Base value
Bias value
D<data>, DB<data>, SB<data>
Without unit
Without polarity
change
13 to 21
With polarity
change
16 to 22
D<data>unit, DB<data>unit,
SB<data>unit
With unit
Without polarity
change
16 to 22
With polarity
change
17 to 26
With range change 37 to 44
Measurement function F0 to F2 Source mode: DC or Pulse operate
and HOLD mode
8
Integral time IT0 13
IT1 14
IT2 32
IT3 (50 Hz/60 Hz) 52/45
IT4 (50 Hz/60 Hz) 420/350
IT5 (50 Hz/60 Hz) 420/350
Time
parameter*
Th, Td, Tp,
Tw
SP<data>, <data>, <data>,
<data>
15 to 31
Tds SD<data> 9 to 14
Sweep
type*
Linear SN<data>unit Standby mode 9 to 28
Log SG<data>unit 9 to 25
Random SC<data> 6 to 10
Source mode MD0 to MD3 4
Random data setting* N<adrs>, <data>, (unit> P 9 to 17
* The processing time for commands accompanied by <data> changes in accordance with the data length.
Item Program code Condition
Execution
time
Unit: ms
