4.13.1 Storing Measured Data into Data Memory (Memory Store)
4-61
NOTE:
In the following cases, Memory Store ON/OFF and storing operation changes do not take place.
• During free run in the DC, Pulse source modes
• In the Operate status of the sweep source mode
Table 4-17 Comparison of Storing Measured Data
Normal Burst
Recommended Application
Low speed measurement
When storing measured
data fore regular measure-
ments such as DC or Pulse
measurement.
High speed measurement
When reading the mea-
sured data after measuring
a number of times such as
Sweep measurement.
Minimum repeat time 10 ms 4 ms
Measured value display Displays in real time
Displays in idle time of
measurement tasks or when
measurement is not per-
formed.
Data output
Read the latest data by ENTER
key
Available Not available
RECALL and RNI commands Available
Operation when Memory Full
SLOT indicator flashes.
MFL (bit 10) of the device event register becomes HI.
Storing data is stopped.
Measurement stops.
Sweep mode: STOP
DC or Pulse mode: HOLD
Comparator
calculation
result
Complete Out HI/GO/LO signal
Outputs in real time
No output
Buzzer
HI/GO/LO display
Displays in idle time of
measurement tasks or when
measurement is not per-
formed.
(*) Integration time: 500 s. Source delay: 10 s. Measure delay: 300 s.
