4.7 Limiter (Compliance)
4-34
4.7 Limiter (Compliance)
For a voltage source, the current limiter is set. For a current source, the voltage limiter is set.
Appropriate settings of these limiters can prevent damage due to over-voltage and over-current to the device.
The 6243/44’s limiters for both voltage and current have both + and - polarities, and the set limiter values
(non-polar) are applied for both + and - polarities.
NOTE: When an external power source (V B ), such as a battery is connected, set the voltage source value (V S ) and
voltage limiter value (V
L ) to a value higher than the V B as shown below.
|V
B | <|V S | or |V B |< |V L |
If V S or V L is set to a smaller value than V B , overload or reverse polarity source may be generated.
4.7.1 Limiter Setting Ranges
The limiter setting range is restricted by the source value.
Table 4-10 and Table 4-11 show the limiter setting ranges in relation to the source values.
• The minimum setting value for the limiter is 300 digits of the limiter range. Lower setting than this
is not possible.
Table 4-10 Limiter Setting Range in Relation to the Source Value (6243)
Source value Limiter
Voltage source
0 |Vs| 32 V 300 nA to 2 A
32 V  |Vs| 64 V 300 nA to 1 A
64 V  |Vs| 110 V 300 nA to 0.5 A
Current source
0 |Is| 0.5 A 3 mV to 110 V
0.5 A  |Is| 1 A 3 mV to 64 V
1 A  |Is| 2 A 3 mV to 32 V
Table 4-11 Limiter Setting Range in Relation to the Source Value (6244)
Source value Limiter
Voltage source
0 |Vs| 7 V 3 A to 10 A
7 V  |Vs| 20 V 3 A to 4 A
Current source
0 |Is| 4 A 3 mV to 20 V
4 A  |Is| 10 A 3 mV to 7 V
