6243/44 DC Voltage Current Source/Monitor Operation Manual
6.3.2 6244 Default Values
6-7
6.3.2 6244 Default Values
Table 6-3 shows the initial values and setting ranges of parameters in the TR6143 mode.
Table 6-3 List of Defaults in the TR6143 Mode (6244) (1 of 2)
Parameter group Parameter item Parameter setting range Factory setting
SOURCE
(Front key)
Source mode DC/PLS/SWP/PSW DC
Source function VS/IS VS
Source range 320 mV to 110 V/32 A to 2 A 110 V
Source value 0.00 mV to 110 V/0.000 A to 2 A
+000.00 V
Limiter value 3 mV to 110 V/300 nA to 2 A 0500.0 mA
MEASURE
(Front key)
Measurement function VM/IM IM
Measurement auto range Auto/Fixed Fixed (3.2 A range)
Null operation ON/OFF OFF
DC and Pulse Trigger mode RUN/HOLD RUN
SWEEP
Sweep type Linear/Log/Random Linear
The start value 0.00 mV to 110 V/0.000 A to  2 A
+000.00 V
The stop value 0.00 mV to 110 V/0.000 A to  2 A
+000.00 V
The step value 0.01 mV to 110 V/0.001 A to 2 A
000.00 V
Log, the step height. 1/2/5/10/25/50 (Step/Decade) 10 Step/Decade
The start address 0 to 4999 0
The stop address 0 to 4999 0
The sweep range Auto/Fixed Auto Range
The sweep repetition number 0 to 1000 1
The reverse mode ON/OFF OFF
The sweep trigger mode Internal/External Internal
TIME
Major delay time 1 ms to 60000 ms
10 ms
Hold time 10 ms to 60000 ms 00010 ms
Period 2 ms to 60000 ms
10 ms
Pulse width 1 ms to 60000 ms 25 ms
Auto range delay time 0 ms to 500 ms 0000 ms
SOURCE
Pulse base value 0.00 mV to 110 V/0.000 A to 2 A 000.00 V
Remote sensing 2 Wire/4 Wire 2 Wire
Limiter /OSC buzzer ON/OFF OFF
MEASURE
Integration time 500 s/1 ms/10 ms/1 PLC/10 PLC/100 PLC 1 PLC
Auto zero ON/OFF ON
Measurement digit 5 1/2-digit, 4 1/2-digit
4 1/2-digit
Measurement ON/OFF ON/OFF ON
Display ON/OFF ON/OFF ON
