9.1.2 Voltage/Current Measurement
9-6
Maximum inductance: Maximum inductance at which oscillation does not occur during current
source or when the current limiter is operating.
9.1.2 Voltage/Current Measurement
Measurement range:
However, measurement resolution becomes as follows when the integration time is 500 s or 1 ms.
Current source range
Current limiter range
Maximum inductance
32 A100 H
320 A500 H
3.2 mA to 2 A 1 mH
Range Range Resolution
Voltage measurement 320 mV
3.2 V
32 V
110 V
0 to  320.000 mV
0 to  3.20000 V
0 to  32.0000 V
0 to  110.000 V
1 V
10 V
100 V
1 mV
Current measurement 32 A
320 A
3.2 mA
32 mA
320 mA
2 A
0 to  32.0000 A
0 to  320.000 A
0 to  3.20000 mA
0 to 32.0000 mA
0 to  320.000 mA
0 to  2000.00 mA
100 pA
1 nA
10 nA
100 nA
1 A
10 A
Integral time Resolution (digits)
500 s5
1 ms 3
