6243/44 DC Voltage Current Source/Monitor Operation Manual
3.4.1 6243 Setting Ranges and Factory Settings
3-21
MENU
MEASURE
Integration time
Auto zero
Number of digits for measurement
Measurement ON/OFF
Display ON/OFF
500 s/1 ms/10 ms/1 PLC/10 PLC/100 PLC
ON/OFF
5 1/2 or 4 1/2
ON/OFF
ON/OFF
1 PLC
ON
5 1/2
ON
ON
COMPARATOR
Comparator calculation
Comparator -upper limit
Comparator -lower limit
Comparator result buzzer
ON/OFF
0.000 mV to  110 V/0.0000 A to  2 A
0.000 mV to  110 V/0.0000 A to  2 A
ON/OFF
OFF
+00.0000 A
+00.0000 A
OFF
EXT.SIGNAL
External control signal
Complete output mode
External Control signal - pulse
width
OPR In (On/Off)/Interlock/OPR Out
Complete Out (Front/End/HI/GO/LO)/
Busy (In/Out)
20 s/100 s
Operate Off In
Complete Out End
20 s
SYSTEM
Power frequency
GPIB address
Talker only
Header
Calibration mode
50 Hz/60 Hz
00 to 30
Addressable/Talk Only
ON/OFF
ON/OFF
50 Hz
01
Addressable
ON
OFF
RANDOM EMORY Random memory
0 to 4999 [0.00 mV to  110 V/
0.000 A to  2 A]
+000.00 mV
MEASURE BUFFER Measurement buffer store NORMAL/BURST/OFF OFF
Panel key Parameter group Parameter type Range Factory setting
