6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.10 GPIB Code List
5-24
TIME Time parameter SP SP <data1>, <data2>, <data3>, <data4>
<data1>:Hold time (00003 to 60000)
<data2>:Major delay time (000.30 to 60000)
<data3>:Period (002.00 to 60000)
<data4>:Pulse width (001.00 to 60000) (Unit: ms)
Only the pulse width can be omitted.
Default value: SP00010, 004.00, 050.00, 025.00
SP? The time parameter query command.
Responds with: SPaaaaa, bbbbb, ccccc, ddddd
aaaaa: Hold time
bbbbb: Major delay time
ccccc: Period
ddddd: Pulse width (Unit: ms)
Source delay time SD SD <data>
<data>: Source delay time (000.01 to 60000) (Unit: ms)
Default value: SD000.01
SD? The source delay time query command.
Responds with: SDaaaaa
aaaaa: Source delay time (Unit: ms)
Measurement auto
range delay
RD RD <data>
<data>: Auto range delay time (00000 to 00500) (Unit: ms)
Default value: RD00000
RD? The auto range delay time query command.
Responds with: RDaaaaa
aaaaa: The auto range delay time (Unit: ms)
START
TRIGGER
The trigger mode for
the DC pulse source
mode
M0 RUN (Free run)
M1 HOLD (Hold)
M? The DC pulse trigger mode query command.
Responds with M...
The trigger mode for
the sweep source
mode
ST0 Automatic trigger mode
ST1 External trigger mode
ST? The sweep trigger mode query command.
Responds with ST...
Trigger *TRG DC mode
When HOLD is set: Measurement trigger
Sweep mode
Automatic trigger sweep: The sweep starts and pauses.
External trigger sweep: The sweep starts and triggers signal output.
Sweep cancellation SWSP The sweep stops. (The value is returned to the bias value.)
EXT.SIGNAL The Operate Signal
signal setting
OP0 The operate OFF signal is input. (IN)
OP1 The operate ON or OFF signal is input. (IN)
OP2 The interlock is input. (IN)
OP3 The Operate Signal is output. (OUT)
OP? The Operate Signal setting query command.
Responds with OP...
The Complete/Busy
signal setting
CP0 COMPLETE signal output timing: The measurement starts. (Front)
CP1 The COMPLETE signal output timing: The measurement is completed. (End)
CP2 The COMPLETE signal output timing: The comparison operation HI.
CP3 The COMPLETE signal output timing: The comparison operation GO.
CP4 The COMPLETE signal output timing: The comparison operation LO.
CP5 The BUSY signal is input.
CP6 The BUSY signal is output.
CP? The Complete/Busy signal setting query command.
Responds with CP...
The external single
wire output signal
pulse width setting
*c
CW0 20 s
CW1 100 s
CW? The query command that sets the external single wire output signal pulse width.
Responds with CW...
*c: When specifying this setting to the 6243/44 which uses the ROM version A02 or earlier, a command syntax error occurs.
Table 5-5 GPIB Command List (4 of 9)
Item Command Description Default
Operation
During DC/
PLS operation
During sweep
operation
To Next Page
