6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.10 GPIB Code List
5-26
SWEEP
(Continued)
The sweep
repetition number
SS SS <data>
<data>: The sweep repetition number(0 to 1000)
The sweep can be repeated continuously when set to 0.
Default value: SS0001
SS? The sweep repetition query command
Responds with SS...
Reverse mode SV0 Reverse OFF
SV1 Reverse ON
SV? The reverse mode query command
Responds with SV...
Random sweep
memory data setting
N The optimal range is automatically set.
P N <data1>, D <data2>UNIT, D <data3>UNIT, , P
<data1>: The memory address (0 to 4999)
<data2>: The voltage or current source value at the <data1> address
<data3>: The voltage or current source value at the <data1> + 1 address
UNIT: Unit
An error occurs when an unused unit in the current source function is specified.
P: The random sweep memory data settings are completed.
Default value (6243): D+000.00E-3V (Voltage function)
D+00.000E-6A (Current function)
Default value (6244): D+000.00E-3V (Voltage function)
D+000.00E-6A (Current function)
*2
Random sweep
memory data
settings
N? The random sweep memory data query command
N? <data>
<data>: Memory address (0 to 4999)
Response: Nddd, DaaaaaaE+aUNIT, P
ddd: Memory address
aaa: Voltage or current source value
Units: V or A
P: Terminator
The voltage and current value responses depend on the current source function.
NP? The random sweep memory setting query command.
Responds with: The random sweep memory setting is completed. : 0
The random sweep memory is being set. :1
Saving and clearing
random sweep
memory data
RSAV Saves the random sweep data in the memory.
RCLR Initializes the random sweep data.
(The saved data is not initialized.)
MEASURE
BUFFER
(STORE)
Measurement buffer
memory
Memory store
mode
SM0 OFF
SM1 Normal (NORMAL-ON)
SM2 Burst (BURST-ON)
SM? The measurement data buffer query command
Responds with: SM...
The measurement
buffer memory
Stored data query
command.
SZ? Response: nnnn: The amount of stored data in the measurement buffer memory (0 to 5000) 0 *2
Clearing the
measurement buffer
memory
RL Clears the measurement buffer memory.
(RECALL) Switches the data
output mode and
specifies a recall
number
RN0 RN0, <adrs>”
Clears the measurement buffer memory recall mode.
<adrs>: Recall data number (0 to 4999)
The address is not changed when <adrs> is omitted.
RN1 RN1, <adrs>
Sets the measurement buffer memory recall mode.
<adrs>: Recall number (0 to 4999)
The address is not changed when <adrs> is omitted.
When data is recalled using ENTER
The recalled data has the same format as that of the measurement data output(ASCII)
With the header ON and OFF
The recall data number is incremented after the data output.
When no data is stored in the specified number
Output: EE +888.888E+8 (omitted).
No recall data is incremented at this point.
The measurement buffer memory data is not deleted when it is recalled.
Table 5-5 GPIB Command List (6 of 9)
Item Command Description Default
Operation
During DC/
PLS operation
During sweep
operation
.........
