6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.10 GPIB Code List
5-29
CALIBRATION Calibration mode XENT Enters the calibration mode. (Cal Switch ON + operation)
XOUT Exit the calibration mode. (Cal Switch OFF + standby) When the range and polarity are set in the
calibration mode.
X? The calibration switch status query command
Responds with: X0: OFF, X1: ON
Normal and calibration modes
XX? The calibration mode query command
Responds with: XX0 for the normal mode, XX1 for the calibration mode
Executing
calibration
XVS Voltage source function calibration When the range and polarity are set in the
calibration mode.
XVM Voltage measurement function calibration
XIS Current source function calibration
XIM Current measurement function calibration
XR3 32 A Range
XR4 320 mV 320 A
XR5 3.2 V 3.2 mA
XR6 32 V/20 V 32 mA
XR7 110 V 320 mA
XR8 2 A/3.2 A
XR9 10 A
XS+ Positive polarity source
XS- Negative polarity source
XNXT Changes the calibration mode (Continues with the following calibration.) When in the calibration mode
XD Performs calibration in the current setting range.
XD <data>: The DMM reading value
Zero point and full scale point calibration
Zero and full scale point calibration in the
calibration mode
XDN1 - 0.5 count Source calibration
Calibration coefficient in the current source range
(zero, gain) is corrected.
Zero and full scale calibration in the calibra-
tion mode
XDN2 - 5 count
XDN3 - 50 count
XDN4 - 500 count
XDN5 - 5000 count
XUP1 + 0.5 count Source calibration
Calibration coefficient in the current source range
(zero, gain) is corrected.
XUP2 + 5 count
XUP3 + 50 count
XUP4 + 500 count
XUP5 + 5000 count
Saving or clearing
calibration
coefficient
XWR Saving the calibration coefficient into memory When the range and polarity are set in the
calibration mode.
XINI Initializing the calibration coefficient
Table 5-5 GPIB Command List (9 of 9)
Item Command Description Default
Operation
During DC/
PLS operation
During sweep
operation
