6.4.2 Data Output Format in the TR6143 Mode (Talker)
6-13
• Fixed-point part and exponent part
The fixed-point part and exponent part are determined by the source/measurement function,
range, and number of measurement digits.
• Block delimiter
A block delimiter is output to indicate the end of one set of data.
The block delimiter can be specified by commands.
Measurement
function
Range
Fixed-point
Exponent
value
5 1/2-digit
measurement
(eight characters)
4 1/2-digit measurement
(seven characters)
Voltage
320 mV  ddd.ddd  ddd.dd E - 3
3.2 V  d.ddddd  d.dddd E + 0
32 V/20 V  dd.dddd  dd.ddd E + 0
110 V  ddd.ddd  ddd.dd E + 0
Current
32 A  dd.dddd  dd.ddd E - 6
320 A  ddd.ddd  ddd.dd E - 6
3.2 mA  d.ddddd  d.dddd E - 3
32 mA  dd.dddd  dd.ddd E - 3
320 mA  ddd.ddd  ddd.dd E - 3
2 A/3.2 A  d.ddddd  d.dddd E + 0
10 A  dd.dddd  dd.ddd E + 0
Over range +999.999 +999.99 E + 9
Block delimiter Setting command Default setting
CR LF + EOI DL0
LF DL1
EOI DL2
