6243/44 DC Voltage Current Source/Monitor Operation Manual
8.1.5 Calibration Procedure
8-6
7. Rotate the Data knob to adjust so that the DMM measured value comes within
the tolerance range shown in Section 8.1.4, “Calibration Points and Tolerance
Range.”
The calibration can be performed by moving the cursor with the and but-
tons and selecting the significance with one click-rotation of the Data knob at a
time.
For changing the source value using the Data knob, wait until the DMM mea-
sured value becomes stable.
8. Upon completion of zero calibration, press the button.
The full calibration mode is invoked.
9. Calibrate so that the DMM measured value comes within the tolerance range
shown in Section 8.1.4, “Calibration Points and Tolerance Range” in the same
manner as for zero calibration.
10. Upon completion of full calibration, press the button.
The range and polarity setting screen shown in Step 4 returns.
11. Press the POLARITY - button, and calibrate the minus source value using the
procedures described in steps 6 to 11.
12. Calibrate the other ranges in the same manner by selecting the range and polarity
on the setting screen in step 4, and perform the calibration by using the proce-
dures described in steps 6 to 11.
13. Upon completion of voltage source calibration, press the button.
The calibration item selection screen appears.
Cursor
number
Value generated by rotating the data knob incrementally
Range
110 V Ranges other than 110 V
1
2
3
4
5
0.21363
2.1363
21.363
213.63
2136.3
0.53407
5.3407
53.407
534.07
5340.7
Full CAL
VS:+300.00mV : 54321
