6243/44 DC Voltage Current Source/Monitor Operation Manual
8.1.5 Calibration Procedure
8-8
9. Upon completion of full calibration, press the button.
The range setting screen shown in step 1 returns.
10. Calibrate the other ranges in the same manner by selecting the range on the range
setting screen in step 1, and perform the calibration by using the procedures
described in steps 3 to 9.
11. Upon completion of voltage measurement calibration, press the button.
The calibration item selection screen appears.
(3) Saving calibration data
NOTE: Upon completion of calibration, be sure to store the calibration data in the nonvolatile memory.
If the data is not saved following calibration, the source values and the measurement values prior
to the calibration are valid.
1. Select Save Cal-data on the calibration item selection screen in the calibration
mode and press the button.
2. Press the DIRECT button.
Upon saving of calibration data, “Done” appears.
(4) Exiting calibration
NOTE: Upon completion of calibration, be sure to set Cal Switch Set to OFF.
1. Press the button on the calibration item selection screen.
The following screen appears asking whether or not the data is to be saved.
2. To save the data, press the 1 button. - or -
To exit without saving the data, press the 0 button.
The standby status is invoked and the parameter selection screen appears.
3. Select the Cal Switch Set parameter and set it to OFF.
4. Press the EXIT button.
The normal measurement screen returns.
This completes calibration.
Save Cal-data
Execute (Press DIRECT Key)
AZERO
Save?
Cancel :’0’ Save :’1’
