6243/44 DC Voltage Current Source/Monitor Operation Manual
3.3.6 LIMIT key (Limiter Setting)
3-8
3.3.6 LIMIT key (Limiter Setting)
Pressing the LIMIT key toggles the setting between the source value change mode and the limiter value
change mode.
Source value change mode:
The cursor (flashing) indicates a digit of the source value and the following keys
are enabled for changing the source value.
• RANGE (Down), (Up) keys
• the , keys and the Data knob
• Numeric value setting using the direct input mode
Limiter value change mode:
The cursor (flashing) indicates a digit of the limiter value and the keys mentioned
above are enabled for changing the limiter value.
3.3.7 MENU key (Setting Parameters)
Pressing the MENU key displays the parameter group selection screen.
The parameter groups and the parameters are as follows:
1. Select the desired parameter group by rotating the Data knob.
Press the key to display the parameter selection screen.
2. Select the desired parameter by rotating the Data knob.
Press the key to enable setting and modification of the parameter.
3.3.7.1 SWEEP (Sweep Parameters)
Selecting SWEEP and pressing the key enables selection of parameters related to the sweep source.
SWEEP TYPE Selects the sweep type between DC sweep and pulse sweep
source mode.
Linear: Linear sweep
Log: Log (logarithm) sweep
Random: Sweep by the memory data set in the random
memory. (Random Sweep)
Bias Value Enables the bias value setting (source value in stop condition).
Start Value Enables the start value setting for linear sweep and log sweep.
Stop Value Enables the stop value setting for linear sweep and log sweep.
