Mounting the Robot
Adept Cobra i600/i800 Robot User’s Guide, Rev G 19
2.4 Environmental and Facility Requirements
The Adept robot system installation must meet the operating environment requirements
shown in Table 2-1.
2.5 Mounting the Robot
Mounting Surface
The Adept Cobra i600 and i800 robots are designed to be mounted on a smooth, flat, level
surface. The mounting structure must be rigid enough to prevent vibration and flexing
during robot operation. Adept recommends a 25 mm (1 in.) thick steel plate mounted to a
rigid steel tube frame. Excessive vibration or mounting flexure will degrade robot
performance. Figure 2-2 shows the mounting hole pattern for the Adept Cobra i-series
robots.
NOTE: On the underside of the base there is a hole and a slot that can be
used as locating points for user-installed dowel pins in the mounting
surface; see Figure 2-2. Using locating pins can improve the ability to
remove and reinstall the robot in the same position.
Table 2-1. Robot System Operating Environment Requirements
Ambient temperature 5° to 40° C (41° to 104° F)
Humidity 5 to 90%, non-condensing
Altitude up to 2000 m (6500 ft)
Pollution degree 2
Robot protection class IP-20 (
NEMA Type 1)
NOTE: See Section 7.1 on page 91 for robot dimensions.
