Technical Specifications
92 Adept Cobra i600/i800 Robot User’s Guide, Rev G
Figure 7-2. Adept Cobra i800/s800 Top and Side Dimensions
Required
clearance
to open
AIB Chassis
31
Required
cable
clearance
417
183
200
918
894
394
342
184
0
46
37
800
425
0
234
Units in mm
