Dimension Drawings
Adept Cobra i600/i800 Robot User’s Guide, Rev G 93
Figure 7-3. Dimensions of the Camera Bracket Mounting Pattern
Cobra s/i600 4X M4x0.7-6H
Cobra s/i800 4X M4x0.7-6H
+.10
-.03
6
10
45
∅3.0
∅3.0
Cobra s/i600
2X
54
8
10
+.10
-.03
7
Cobra s/i800 2X
