Ados T060E - Management of T060 E Relays

1569‐PT060EE1 Rev.7 Page13of62
2.5 Management of relays
Thebasicinstrumentisequippedwithfiverelaysthatcanbeconfiguredasrequired.

Agenerallyopencontact(NA)notundervoltageisavailableforeachrelay.

Therelays’operationislinkedtotheconditionsdefinedintheconfigurationphase.

The relays’ commutation takes place when the threshold value set in the configuration phase (SET # parameter) is
reached and remains in this condition for a timeframe equal to or exceeding the alarm minimum time (DAL #
parameter).Itisrestoredinnormalconditionswhentheweightvalueisdropped
belowthevaluedeterminedbythe
sum ofthe thresholdvalue and the configured hysteresis value (DB# parameter) and remains in this condition for a
timeframeequaltoorexceedingtheminimumnormaltime(DOH#parameter).

Thechangeoftherelayoperationcausetheclearanceofsetpointsvalues
.


Eachrelaycanbeconfiguredtooperateinoneofthefollowingmodes:
F A I L 1
Loadcellconnectionfault(FAIL).Thealarmstatusistriggered
whentheFAILconditionispresent.

L O N 1
Minimumalarm(LON)
Thealarmstatusistriggeredwhentheweightvalueislower
thanorequaltothethresholdvalue.

H I N 1
Maximumalarm(HIN)
Thealarmstatusistriggeredwhentheweightvalueisgreater
thanorequaltothethresholdvalue.

L O G 1
Minimumalarm(LOG).Thealarmistriggered,regardlessof
theresetvalue.

Thealarmstatusistriggeredwhentheweightvalueislower
thanorequaltothethresholdvalue.

H I G 1
Maximumalarm(HIG).Thealarmistriggered,regardlessof
theresetvalue.

Thealarmstatusistriggeredwhentheweightvalueislower
thanorequaltothethresholdvalue.

T O T N
Alarmonthetotalvalueofthetwochannels(TOTG).The
alarmstatusistriggeredwhentheweightvalueisgreater
thanorequaltothethresholdvalue.

T O T G
Alarmonthetotalvalueofthetwochannels(TOTG).The
alarmistriggered,regardlessoftheresetvalue.

Thealarmstatusistriggeredwhentheweightvalueisgreater
thanorequaltothethresholdvalue.


O N
Therelayiskeptconstantlyenergized.

